Hand Held Air Impact Markers
CMT hand held air impact marker Model 75AT - standard Model 85AT - high Model 95 - extreme marking force.
Model 75 - Standard Power
Model 75 Standard powered hand held air impact marker. This unit is great for indention marking of inspection and QC marks. Marking small characters into mild metal |
Model 85 - High Power
Model 85 High powered hand held air impact marker. This unit is great for indention marking of inspection and QC marks. Marking (1) 1/8" character into standard soft steel. |
Model 95 - Extreme Power
Model 95 extreme powered hand held air impact marker. Great for marking date codes and part numbers. Extra tool holders are helpful for quick changeover of marking legends. |
Filter, Regulator, Lubricator
Accessory for use with the hand held air impact markers Model75AT, 85AT, and 95. The FRL provide the regulator and lubricator required for proper use of these tools. |
<
Hand Held Air Impact Marker Selection Guide
Selection is based on MATERIAL, character SIZE, and the NUMBER of characters.
Material Aluminum
Material Brass
Material Steel
Material Carbon Steel
Model 75ATOB standard pressure with round pocket to hold (1) 1/8" or smaller character CM8X.
Model 85ATOB high pressure with round pocket to hold (1) 3/16" or smaller character CM8X
Model 095OB extreme pressure with round pocket to hold (1) 1/4" or smaller character CM8X
Model 75ATOA standard pressure with square pocket to hold (4) 1/16" CMG06 characters.
Model 095ON-NA50 extreme pressure marker and holder combination for (5) to (8) 1/16" caracters. Model 095ON-NA75 marker and holder combination for (9) to (12) 1/16" characters. The CMG06 standard 1/16" characters are used in both holders.
Model 085ATOA high pressure with square pocket to hold (2) 1/8" CMG13 characters.
Model 095ON-NA50 extreme pressure marker and holder combination for (3) to (4) 1/8" characters. Model 095ON-NA75 marker and holder combination for (5) to (6) 1/8" characters. The CMG13 standard 1/8" characters are used in both holders.
Model 095ON-NB75 extreme pressure marker and holder combination for (3) to(4) 1/8" characters. The CMG19 standard 3/16" characters are used in this holder.
Model 095ON-NC50 extreme marker and holder combination for (2) 1/4" characters. The CMG25 standard 1/4" characters are used in this holder.
Model 75ATOB standard pressure with round pocket to hold (1) 1/8" or smaller character CM8X.
Model 85ATOB high pressure with round pocket to hold (1) 3/16" or smaller character CM8X
Model 095OB extreme pressure with round pocket to hold (1) 1/4" or smaller character CM8X
Model 85ATOA high pressure with square pocket to hold (4) 1/16" CMG06 characters.
Model 095ON-NA50 marker and holder combination for (5) to (8) 1/16" caracters. Model 095ON-NA75 marker and holder combination for (9) to (12) 1/16" characters. The CMG06 standard 1/16" characters are used in both holders.
Model 095OA extreme pressure with square pocket to hold (2) 1/8" CMG13 characters.
Model 095ON-NA50 marker and holder combination for (3) to(4) 1/8" characters. Model 095ON-NA75 marker and holder combination for (5) to (6) 1/8" characters. The CMG13 standard 1/8" characters are used in both holders.
Model 095ON-NB75 marker and holder combination for (3) to (4) 1/8" characters. The CMG19 standard 3/16" characters are used in this holder.
Model 095ON-NC50 marker and holder combination for (2) 1/4" characters. The CMG25 standard 1/4" characters are used in this holder.
Model 75ATOB standard pressure with round pocket to hold (1) 3/32" or smaller character CM8X.
Model 85ATOB high pressure with round pocket to hold (1) 1/8" or smaller character CM8X
Model 095OB extreme pressure with round pocket to hold (1) 1/4" or smaller character CM8X
Model 85ATOA high pressure with square pocket to hold (4) 1/16" CMG06 characters.
Model 095ON-NA50 marker and holder combination for (5) to (8) 1/16" caracters. Model 095ON-NA75 marker and holder combination for (9) to (12) 1/16" characters. The CMG06 standard 1/16" characters are used in both holders.
Model 095OA extreme pressure with square pocket to hold (2) 1/8" CMG13 characters.
Model 095ON-NA50 marker and holder combination for (3) to(4) 1/8" characters. The CMG13 standard 1/8" characters are used in both holders.
Model 095ON-NB75 marker and holder combination for (3) to (4) 1/8" characters. The CMG19 standard 3/16" characters are used in this holder.
Model 095ON-NC50 marker and holder combination for (2) 1/4" characters. The CMG25 standard 1/4" characters are used in this holder.
Model 75ATOB standard pressure with round pocket to hold (1) 1/16" or smaller character CM8X.
Model 85ATOB high pressure with round pocket to hold (1) 3/32" or smaller character CM8X
Model 095OB extreme pressure with round pocket to hold (1) 1/4" or smaller character CM8X
Model 85ATOA high pressure with square pocket to hold (4) 1/16" CMG06 characters.
Model 095OA extreme pressure with square pocket to hold (4) 1/16" characters. Model 095ON-NA50 marker and holder combination for (5) to (8) 1/16" caracters. The CMG06 standard 1/16" characters are used in both holders.
Model 095OA extreme pressure with square pocket to hold (2) 1/8" CMG13 characters.
Model 095ON-NA50 marker and holder combination for (3) to(4) 1/8" characters. The CMG13 standard 1/8" characters are used in both holders.
Model 095ON-NB75 marker and holder combination for (3) to (4) 1/8" characters. The CMG19 standard 3/16" characters are used in this holder.
Your marking parameters Not Found in the selection guide ?
CMT can help you make your mark!
Accessories and Required tooling
CMG Rectangular Groove Type
Rectangular groove type for use with models 75ATOA, 85ATOA, 95ATOA, and 95N style holders
Learn More075FRL Filter, Regulator, Lubricator
Complete air preparation for the models 75AT, 85AT, and 95.
